Information
Seogimhaesandan-ro, Gimhae-si, Gyeongsangnam-do, South Korea
+82 55-321-3182
-
Overview
- Summary
- ACE Co., Ltd. is a company specializing in the production of auto traps and turbo traps for efficient condensate discharge from compressors for over 20 years. Its focus is on maximizing customer benefits through the production of top-quality products based on ISO quality management systems. The company strives to produce world-class auto traps, exporting to over 30 countries including Germany and the United States. It possesses non-powered, zero air-loss drain trap technology.ACE Co., Ltd. is a company specializing in the production of auto traps and turbo traps for efficient condensate discharge from compressors for over 20 years. Its focus is on maximizing customer benefits through the production of top-quality products based on ISO quality management systems. The company strives to produce world-class auto traps, exporting to over 30 countries including Germany and the United States. It possesses non-powered, zero air-loss drain trap technology.
- Key Products/Technologies
- **Auto Trap (Acetrap)**: A non-powered, diaphragm-type mechanical trap for automatic discharge of condensate generated in compressor compressed air lines. The product line includes Acetrap15 and Acetrap20 models, capable of handling various capacities and pressure conditions. The Acetrap15 model features a 1/2-inch inlet, 3/8-inch outlet, 1.2-16 bar pressure range, 0-60°C temperature range, a discharge capacity of up to 400 l/h, and applicability for 3-50 HP compressors. The Acetrap20 model offers a 3/4-inch inlet, 1/2-inch outlet, 1.2-16 bar pressure range, 0-60°C temperature range, a discharge capacity of up to 1000 l/h, and applicability for 20-100 HP compressors. Options include NBR diaphragms (0-60°C, oil-resistant) suitable for oily environments and VITON diaphragms (0-100°C, heat and chemical-resistant) for harsh conditions. Additional options such as strainer filters for scale removal, heaters for freeze protection, brackets for trap fixation, air vents, and air distributors are available.**Auto Trap (Acetrap)**: A non-powered, diaphragm-type mechanical trap for automatic discharge of condensate generated in compressor compressed air lines. The product line includes Acetrap15 and Acetrap20 models, capable of handling various capacities and pressure conditions. The Acetrap15 model features a 1/2-inch inlet, 3/8-inch outlet, 1.2-16 bar pressure range, 0-60°C temperature range, a discharge capacity of up to 400 l/h, and applicability for 3-50 HP compressors. The Acetrap20 model offers a 3/4-inch inlet, 1/2-inch outlet, 1.2-16 bar pressure range, 0-60°C temperature range, a discharge capacity of up to 1000 l/h, and applicability for 20-100 HP compressors. Options include NBR diaphragms (0-60°C, oil-resistant) suitable for oily environments and VITON diaphragms (0-100°C, heat and chemical-resistant) for harsh conditions. Additional options such as strainer filters for scale removal, heaters for freeze protection, brackets for trap fixation, air vents, and air distributors are available.
- **Turbotrap**: An auto trap specifically designed for large-capacity compressors, turbo compressor intercoolers, and challenging environments prone to pipe scale and oil leakage due to aging equipment. Its mechanism involves a ball float linked to a ball valve, making it suitable for sites with high scale accumulation or large volumes of condensate. Models like Turbotrap 50N and Turbotrap 100N are offered, demonstrating stable operation in extreme conditions such as contamination, explosion-proof zones, aged piping, and oil-containing environments. Repair kits, frost protection heaters, NPT taps, and remote alarms are among the available parts and options.**Turbotrap**: An auto trap specifically designed for large-capacity compressors, turbo compressor intercoolers, and challenging environments prone to pipe scale and oil leakage due to aging equipment. Its mechanism involves a ball float linked to a ball valve, making it suitable for sites with high scale accumulation or large volumes of condensate. Models like Turbotrap 50N and Turbotrap 100N are offered, demonstrating stable operation in extreme conditions such as contamination, explosion-proof zones, aged piping, and oil-containing environments. Repair kits, frost protection heaters, NPT taps, and remote alarms are among the available parts and options.
- Core Advantages
- Over 20 Years of Expertise in Condensate Discharge: The company possesses deep experience and technical know-how, having specialized in the production of compressor condensate discharge products for more than two decades. High reliability is ensured through rigorous testing, including over one million cycles during product design.Over 20 Years of Expertise in Condensate Discharge: The company possesses deep experience and technical know-how, having specialized in the production of compressor condensate discharge products for more than two decades. High reliability is ensured through rigorous testing, including over one million cycles during product design.
- Non-Powered, Zero Air-Loss Technology: Development and production of mechanical traps that operate without external power supply. Implementation of zero air-loss technology, preventing any air leakage during condensate discharge, thereby minimizing energy loss.Non-Powered, Zero Air-Loss Technology: Development and production of mechanical traps that operate without external power supply. Implementation of zero air-loss technology, preventing any air leakage during condensate discharge, thereby minimizing energy loss.
- Product Design Adaptable to Diverse Industrial and Harsh Conditions: Capability to operate stably not only in standard environments but also in challenging conditions such as high scale, oil-contaminated environments, aged piping, large condensate volumes, and explosion-proof areas. Key development principles include ease of maintenance, long durability, and a simple, fault-free structure.Product Design Adaptable to Diverse Industrial and Harsh Conditions: Capability to operate stably not only in standard environments but also in challenging conditions such as high scale, oil-contaminated environments, aged piping, large condensate volumes, and explosion-proof areas. Key development principles include ease of maintenance, long durability, and a simple, fault-free structure.
- Acquisition of International Quality and Technical Certifications: Establishment of product standardization and quality assurance systems through ISO 9001:2005 quality management system certification. Validation of technical prowess and quality reliability in overseas markets through European CE certification and patents registered in the United States and Germany.Acquisition of International Quality and Technical Certifications: Establishment of product standardization and quality assurance systems through ISO 9001:2005 quality management system certification. Validation of technical prowess and quality reliability in overseas markets through European CE certification and patents registered in the United States and Germany.
- Global Export Network to Over 30 Countries: Export of products to more than 30 countries worldwide, including Germany, the United States, and Southeast Asia, strengthening global market competitiveness. A track record of receiving the 3 Million Dollar Export Tower Award and Export Merit Award.Global Export Network to Over 30 Countries: Export of products to more than 30 countries worldwide, including Germany, the United States, and Southeast Asia, strengthening global market competitiveness. A track record of receiving the 3 Million Dollar Export Tower Award and Export Merit Award.
- Target Industrie
- Compressor Systems: Provision of essential components for automatic condensate discharge in compressed air systems.Compressor Systems: Provision of essential components for automatic condensate discharge in compressed air systems.
- General Industrial Facilities: Offering drain trap solutions for energy saving and efficient operation across various industrial facilities.General Industrial Facilities: Offering drain trap solutions for energy saving and efficient operation across various industrial facilities.
- Press and Steel Industries: Application of optimized drain traps for press and steel equipment, characterized by frequent scale generation and harsh environments.Press and Steel Industries: Application of optimized drain traps for press and steel equipment, characterized by frequent scale generation and harsh environments.
- Aging Equipment Environments: Condensate management in aging equipment environments prone to pipe scale and oil leakage.Aging Equipment Environments: Condensate management in aging equipment environments prone to pipe scale and oil leakage.
- Major Markets
- Thailand, Southeast AsiaThailand, Southeast Asia
- GermanyGermany
- United StatesUnited States
- Certifications/Patents
- ISO 9001:2005 Quality Management System Certification (acquired in 2009).ISO 9001:2005 Quality Management System Certification (acquired in 2009).
- ISO 14001 Environmental Management System Certification (acquired in 2009).ISO 14001 Environmental Management System Certification (acquired in 2009).
- CE Certification (for ACE DRAIN and HEATER products).CE Certification (for ACE DRAIN and HEATER products).
- United States Patent Registration (related to Acetrap).United States Patent Registration (related to Acetrap).
- German Patent Registration (related to Acetrap).German Patent Registration (related to Acetrap).
- Domestic Patent Registration (for ACE DRAIN and Turbotrap).Domestic Patent Registration (for ACE DRAIN and Turbotrap).
- Utility Model Registration.Utility Model Registration.
- Inno-Biz Certification.Inno-Biz Certification.
- Main-Biz Certification (acquired in 2013).Main-Biz Certification (acquired in 2013).
- Venture Company Certification (acquired in 2013).Venture Company Certification (acquired in 2013).
- 3 Million Dollar Export Tower Award (2012).3 Million Dollar Export Tower Award (2012).
- Export Merit Award (2009).Export Merit Award (2009).
- Promising Small and Medium-sized Export Enterprise Certification.Promising Small and Medium-sized Export Enterprise Certification.
- Star Company Selection.Star Company Selection.
Introduction
Location
Seogimhaesandan-ro, Gimhae-si, Gyeongsangnam-do, South Korea
클릭하여 위치 살펴보기
