제품설명
- 제품의 Flicker 측정/검사하는 장비.
- 3CH 개별/동시 검사 가능.
제품사양
Item |
Specification |
Resolution |
VGA ~ UHD |
CH |
3CH 대응 |
Signal |
LVDS, eDP1.3 8Lane, MIPI 8Lane |
Pattern |
Logic Pattern, BMP |
Power |
3CH (VDD1,VDD2,VDD3) Output |
Voltage / Current monitoring |
Programmable Power Sequence support |
GUI Program |
Model Create & Edit
Log File Support |
DrawMagic
(Pattern Edit) |
Pattern Create & Edit, BMP Resize |
Remote Control |
Pattern Up/Down. Power On/Off.
Frequency & Gray Variation. |
FunctionFunction |
Flicker 검사 |
3CH 동시 or 개별 제어 가능 |
|
