| Size |
1-1/2″ to 60″(DN40 … DN1500) |
| Rating |
ANSI 150Lb to 600Lb
JIS 10K to 63K
PN10 to PN100 |
| Temp. Range |
-150˚F to +1,050˚F / -100˚C to +565˚C
Option : -320˚F to +1,562˚F / -196˚C to +850˚C |
| Materials |
Carbon steel(WCB,WCC), Stainless steel(CF8, CF8M, CF3, CF3M),
Chrome-moly(WC6,WC9,C12A), other alloys
|
| End Connections |
Wafer Flange less, RF/FF/RTJ Flanged, Butt weld |
| Actuators |
Spring-diaphragm, Cylinder, Motorized, Electro-Hydraulic |
| Applications |
Fuel gas control, Low Pressure Steam & Water, General Services, Flash Tank,
Condensate Recirculation, Auxiliary Steam, Deaerator Pegging Steam
|
