Shinmyung Tech Co., Ltd., established in 1987, is a specialized marine equipment company engaged in the design, manufacturing, sales, and customer service of robust equipment capable of withstanding harsh marine environments. The company directly supplies a diverse range of products including cranes, davits, winches, reels, capstans, motors, and pumps to meet the varied demands of shipyards and shipowners. It is a marine equipment specialist that supplies its products globally, securing expertise in the marine industry sector.

신명테크(주)는 1987년에 설립된 해양 장비 전문 기업으로, 거친 해양 환경에 견딜 수 있는 장비의 설계, 제조, 판매 및 고객 서비스를 제공하는 기업. 조선소와 선주의 다양한 요구에 부응하기 위한 크레인, 데빗, 윈치, 릴, 캡스턴, 모터, 펌프 등의 제품군을 직접 공급하는 기업. 전 세계에 해양 장비를 공급하며 해양 산업 분야에서 전문성을 확보한 기업.

MODEL	WINDING LOAD	WINDING CAPACITY		DRUM DIA.
	(kg)	MOTOR	SPEED	(mm)
	(kg)	(PS)	(m/min)	(mm)
SMCAP-A	500	4.5	15	200
	1000	7.3	17.5	250
	2000	12	20	360
	4000	12	8	360

MODEL	WINDING LOAD	WINDING CAPACITY		DRUM DIA.
	(kg)	MOTOR	SPEED	(mm)
	(kg)	(kW)	(m/min)	(mm)
SMCAP-E	500	3.7	15	200
	1000	5.5	17.5	250
	2000	11	20	360
	4000	11	8	360

MODEL	WINDING LOAD	WINDING CAPACITY		DRUM DIA.	REMARK
	(ton)	MOTOR	SPEED	(mm)	SPEED CONDITION
		(kW)	(m/min)
SMCAP-E/H	5	22	12	360	SINGLE SPEED
		11	6/12		TWO SPEED
	10	30	12	450	SINGLE SPEED
		15	6/12		TWO SPEED
	15	45	12	600	SINGLE SPEED
		45	6/12		TWO SPEED
