MODEL

SWL

WORKING
RADIUS(R)

MAX. LIFT

HOISTING

SLEWING

WIRE
ROPE DIA.

DIMENSION (mm)

(ton)

(m)

(m)

MOTOR

SPEED

MOTOR

SPEED

mm

A

B

D

E

F

(PS)

(m/min)

(kW)

(m/min)

SMSHD

0.2

0.8~1.5

15

2.6

5~10

BY GUY ROPE

6

3750

1500

216

600

3000

0.5

0.8~1.5

15

2.6

5~10

BY GUY ROPE

8

3750

1500

216

600

3000

1

0.8~1.5

15

4.5

5~10

BY GUY ROPE

10

3750

1500

267

600

3000
