MODEL
(ON/COAXIAL) |
Optical
magnification |
WD(mm) |
Depth
of field |
Resolution |
NA |
Paraxial
Working
F/# |
F.O.V. |
MOUNT |
TLW65D
- 0.8X |
0.8X |
65mm |
±0.834
mm |
11.2um |
0.03 |
13.3 |
H11.0 x V8.25(2/3"),
H8.0 x V6.0(1/2") |
C-mount |
TLW65D
- 1.0X |
1.0X |
65mm |
±0.666
mm |
11.2um |
0.03 |
16.7 |
H8.8 x V6.6(2/3"),
H6.4 x V4.8(1/2") |
C-mount |
TLW65D
- 1.2X |
1.2X |
65mm |
±0.556
mm |
10.7um |
0.03 |
19 |
H5.33 x V4.0(1/2"),
H4.0 x V 3.0(1/3") |
C-mount |
TLW65D
- 1.5X |
1.5X |
65mm |
±0.337
mm |
7.2um |
0.047 |
15.7 |
H4.26 x V3.2(1/2"),
H3.2 x V 2.4(1/3") |
C-mount |
TLW65D
- 2.0X |
2.0X |
65mm |
±0.142
mm |
4.8um |
0.07 |
14.2 |
H3.2 x V2.4(1/2"),
H2.4 x V1.8(1/3") |
C-mount |
TLW65D
- 2.5X |
2.5X |
65mm |
±0.114
mm |
4.8um |
0.07 |
17.6 |
H2.56 x V1.92(1/2"),
H1.92 x V1.44(1/3") |
C-mount |
TLW65D
- 3.0X |
3.0X |
65mm |
±0.088
mm |
4.47um |
0.075 |
19.9 |
H2.9 x V2.2(2/3"),
H2.1 x V1.6(1/2") |
C-mount |
TLW65D
- 4.0X |
4.0X |
65mm |
±0.062
mm |
4.2um |
0.08 |
24.9 |
H2.2 x V1.6(2/3"),
H1.6 x V1.2(1/2") |
C-mount |
