| Hose Size | Hose I.D. | Hose O.D. | Working Pressure | Burst Pressure | MIN.Bend Radius | Weight | |||||
| mm | Inch | mm | Inch | bar | psi | bar | psi | mm | Inch | kg/m | |
| 3/8″ | 9.5 | 0.38 | 20.3 | 0.80 | 280 | 4060 | 1120 | 16200 | 125 | 5.0 | 0.80 |
| 1/2″ | 12.7 | 0.50 | 23.6 | 0.93 | 280 | 4060 | 1120 | 16200 | 180 | 7.0 | 1.15 |
| 3/4″ | 19.0 | 0.75 | 30.7 | 1.21 | 280 | 4060 | 1120 | 16200 | 240 | 9.5 | 1.44 |
| 1″ | 25.4 | 1.00 | 38.1 | 1.50 | 280 | 4060 | 1120 | 16200 | 305 | 12.0 | 2.15 |
| 1-1/4″ | 32.0 | 1.25 | 47.0 | 1.85 | 280 | 4060 | 1120 | 16200 | 420 | 16.5 | 2.75 |
| 1-1/2″ | 38.0 | 1.50 | 53.6 | 2.11 | 210 | 3040 | 840 | 12100 | 510 | 20.0 | 3.35 |
| 2″ | 50.8 | 2.00 | 66.8 | 2.63 | 175 | 2500 | 700 | 10100 | 635 | 25.0 | 4.60 |
