(*L) = Option
※ Cover Option
● Rating : 250V 20A
● Insulation Resistance : More Than 1000MΩ DC 500V
● Withstand Voltage : AC2000V Per Minute
● Wire Size / Range : AWG14~22
● Maximum Acceptable Temperature : -40°C ~ +85°C
A-B-C Dimension
|
P |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
12 |
13 |
14 |
15 |
16 |
17 |
18 |
19 |
20 |
|
A±0.8 |
- |
39.5 |
50.5 |
61.5 |
72.5 |
83.5 |
94.5 |
105.5 |
116.5 |
127.5 |
138.5 |
149.5 |
160.5 |
171.5 |
182.5 |
193.5 |
204.5 |
215.5 |
226.5 |
237.5 |
|
B±0.5 |
- |
31.5 |
42.5 |
53.5 |
64.5 |
75.5 |
86.5 |
97.5 |
108.5 |
119.5 |
130.5 |
141.5 |
152.5 |
163.5 |
174.5 |
185.5 |
196.5 |
207.5 |
218.5 |
229.5 |
|
C±0.5 |
- |
11 |
22 |
33 |
44 |
55 |
66 |
77 |
88 |
99 |
110 |
121 |
132 |
143 |
154 |
165 |
176 |
187 |
198 |
209 |
|
NO |
Component Part |
Material |
Standard |
Plated |
Remark |
|
1 |
Frame |
P.B.T. |
UL94V-0 |
- |
- |
|
2 |
Terminal |
BRASS |
C2680R |
Sn |
- |
|
3 |
Screw |
SWCH10A |
- |
Ni |
M3.5 * 8 |
|
4 |
WASHER |
SPCC |
|
Ni |
□8.7 * 8.7 |
