ZERONE

ZERONE

Electrosurgical System

Model

Series

Electrosurgical System


Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Contact the manufacturer/supplier.


Description


- Color Graphic User Interface.

Wide TFT LCD mount, clean and shaper image quality, unlike the existing electricity and the innovative new U.I. configuration operation.

-  Best Safety with Feedback System.

 REM(Return Electrode Monitoring) monitors the size of contact area between a patient and the pad. If the size is inappropriate, it automatically blocks the high-frequency current to minimize the danger of burning incidents.

- All Touch Screen System & Key.

Touch screen system through the implementation easier and faster with a parameter setting, external key management can be the same as a touch screen.

- Diversity of Features Bipolar.

Bipolar cut, Biploar blend, Bipolar forced to add features to implement more up-grade the optimal system.

- Endo-Cut(Intra-Cut) (Option1)

Endo-Cut is a monopolar electrosurgical treatment method and a cut which is carried out in intervals(fractionated cut) with software-controlled alternations between cutting and coagulation stages.


- CE, ISO13485, KFDA certified.




Mode
Output Power
Cut
Pure
400W / 200Ω
Blend 1
250W / 200Ω
Blend 2
200W / 200Ω
Blend 3
150W / 200Ω
Coagulation
Contact
120W / 200Ω
Spray
100W / 300Ω
Argon
100W / 300Ω
Bipolar
Coagulation
Standard
100W / 100Ω
Autostart
100W / 100Ω
Forced
 80W / 100Ω
Bipolar
Cut
Cut
120W / 200Ω
Blend
100W / 200Ω


(Option 1)
Endo Cut
Papillotomy
150W / 100Ω
Polypectomy
150W / 100Ω
Coagulation
Soft
 80W / 100Ω



Main Frequency
400, 500 KHz
Power Source
AC120V or AC230V, 50/60 Hz
Protection Class
Class 1, Type CF
Dimension(WxDxH)
388x410x160 mm
Weight
12.5 Kg





ZERONE  ZEUS VISION(OEM)

ZERONE  ZEUS VISION(OEM) 1
