  • ZERONE

    Model
    ZEUS VISION(OEM)
    Series
    Electrosurgical System

    Product Description


    - Color Graphic User Interface.

    Wide TFT LCD mount, clean and shaper image quality, unlike the existing electricity and the innovative new U.I. configuration operation.

    -  Best Safety with Feedback System.

     REM(Return Electrode Monitoring) monitors the size of contact area between a patient and the pad. If the size is inappropriate, it automatically blocks the high-frequency current to minimize the danger of burning incidents.

    - All Touch Screen System & Key.

    Touch screen system through the implementation easier and faster with a parameter setting, external key management can be the same as a touch screen.

    - Diversity of Features Bipolar.

    Bipolar cut, Biploar blend, Bipolar forced to add features to implement more up-grade the optimal system.

    - Endo-Cut(Intra-Cut) (Option1)

    Endo-Cut is a monopolar electrosurgical treatment method and a cut which is carried out in intervals(fractionated cut) with software-controlled alternations between cutting and coagulation stages.


    - CE, ISO13485, KFDA certified.




    Mode
    Output Power
    Cut
    Pure
    400W / 200Ω
    Blend 1
    250W / 200Ω
    Blend 2
    200W / 200Ω
    Blend 3
    150W / 200Ω
    Coagulation
    Contact
    120W / 200Ω
    Spray
    100W / 300Ω
    Argon
    100W / 300Ω
    Bipolar
    Coagulation
    Standard
    100W / 100Ω
    Autostart
    100W / 100Ω
    Forced
     80W / 100Ω
    Bipolar
    Cut
    Cut
    120W / 200Ω
    Blend
    100W / 200Ω


    (Option 1)
    Endo Cut
    Papillotomy
    150W / 100Ω
    Polypectomy
    150W / 100Ω
    Coagulation
    Soft
     80W / 100Ω



    Main Frequency
    400, 500 KHz
    Power Source
    AC120V or AC230V, 50/60 Hz
    Protection Class
    Class 1, Type CF
    Dimension(WxDxH)
    388x410x160 mm
    Weight
    12.5 Kg





    ZERONE  ZEUS VISION(OEM)

    ZERONE  ZEUS VISION(OEM) 1
