Woori Vehicle Washer Co

Woori Vehicle Washer Co

Shopping Cart Washer

Model

Series

Products


Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Contact the manufacturer/supplier.


Description

▶ Power (380VAC 3 phase 5 line)


Classification

Capacity - HP (kw)

Quantity

Entrance transportation system

1/2 HP (0.37 kw)

1 EA

Conveyor system

1.0 HP (0.75 kw)

1 EA

Top brush

1/2 HP (0.37 kw)

1 EA

Side brush

1/4 HP (0.18 kw)

2 EA

Vibration brush

1/2 HP (0.37 kw)

1 EA

Washing pump

1.0 HP (0.75 kw)

1 EA

High pressure washing pump

10. HP (7.50 kw)

1 EA

Dryer

5.0 HP (3.75 kw)

2 EA

Sewage & wastewater treatment system

5.0 HP (3.75 kw)

1 EA

Compressed air

5.0 HP (3.75 kw)

1 EA

Control Power

220VAC single phase & DC24V



Others

1.1/2 HP (1.2 kw)

1 EA

Total power consumption

35.0 HP  (26.5 kw)





Classification Details Quantity

CPU

PLC control

1SET

Indicator

8 inch color (touch screen)

1  EA

Entrance transportation system

Motor Actuation system

1 SET

Exit loading system

Pneumatic Actuation System

1 SET

Conveyor system

2.0/min (1.5/min ~ 2.5/min), 1 car per min

1 SET

High pressure washing device

Magnetic force rotating nozzle

1 SET

Top brush

150φ X 700mm (PE)

2  EA

Side brush

150φ X 750mm (PE)

2  EA

Vibration brush

쇼핑 카트 내면 -50mm (PE)

1  EA

Drug injection system

Antivirus effect (Injector method)

1  EA

Dryer

Top and side incorporated

1 SET

Sewage & wastewater treatment system

Discharging & recycled water

1  EA
