  • Woo Kyung Optics

    USB Fingerprint Sensors
    Model
    SDU03P
    Series
    Biometrics

    Product Description

    SDU03P

    SecuGen Hamsters are the industry's most accurate, rugged, and affordable USB fingerprint readers.
    These high-performance, versatile readers feature advanced optical sensors engineered with patented SEIR™ technology to give you the highest quality in fingerprint biometrics.


    Features

    - Accurate, patented optical USB fingerprint sensor with 500 DPI resolution
    - Auto-OnTM to automatically detect the presence of a finger when placed on the reader
    - Smart CaptureTM for reliable scanning of dry, moist, aged, scarred and difficult-to-scan fingers
    - Hardened optical glass platen that is scratch, impact, corrosion and electrostatic shock resistant
    - Compact and ergonomic design works with any finger or thumb
    - Supports BioAPI, INCITS 378-2004 and ISO 19794
    - Supports SecuGen proprietary, 3rd party and MINEX Certified Template Extractor and Matcher algorithms


    Specification

    Fingerprint Reader

    Optic Module

    SDU03P

    Image Resolution

    500 DPI

    Image Size

    260 x 300 pixels

    Platen Size

    16.1 mm x 18.2 mm

    Sensing Area

    13.2 mm x 15.2 mm

    Image Grayscale

    256 levels (8-bit)

    Light Source

    Red LED

    LED Lifetime (typical)

    60,000 hours

    Imaging Speed (capture time)

    0.2 - 0.5 seconds with Smart Capture

    Electrical / Communication

    Interface

    USB 1.1 Full-Speed, USB 2.0 Hi-Speed

    Supply Voltage

    5 V DC (via USB)

    Maximum Current

    120 mA

    Physical

    Dimensions (W x L x H)

    27 x 40 x 73 mm (without stand)
    53 x 73 x 84 mm (with stand)

    Weight

    100 g (without stand)
    165 g (with stand)

    Cable Length

    1500 mm

    Operating Temperature

    -20o to +65o C

    Operating Humidity

    90% or less RH noncondensing

    Other

    Warranty

    One year limited

    Supported Standards

    ANSI INCITS 378, BioAPI, FIPS 201,
    ISO/IEC 19794-2, ISO/IEC 19794-4

    Compliance

    FCC, CE, RoHS

    Supported Operating Systems

    Windows 7, Vista, XP, 2000, 9x
    Windows Server 2008 R2, 2003
    Android, Java, Linux, Windows CE
