TOP
-공구강 및 고경도강 절삭에 적합
-고이송 정삭 작업에 적합
-우수한 표면조도
-Surface-Treatment : Non-Coating도 가능함
-Suitable for cutting tools steel and hardened steel.
-Suitable finish milling with high feed rate.
-Achieving superb surface finishing.
모델번호 EDP NO. |
인선직경(D) Outside Diameter |
날길이 (L1) Flute Length |
전장(L) Overall length |
생크직경 (D) Shank Diameter |
날수 No. of flute |
나선 Helix |
경도 Hardness |
---|---|---|---|---|---|---|---|
UREK4040 | 4.0 | 13 | 50 | 6 | 4 | 50 | 70 |
UREK4050 | 5.0 | 13 | 50 | 6 | 4 | 50 | 70 |
UREK6060 | 6.0 | 13 | 50 | 6 | 6 | 50 | 70 |
UREK6080 | 8.0 | 13 | 57 | 8 | 6 | 50 | 70 |
UREK6100 | 10.0 | 22 | 72 | 10 | 6 | 50 | 70 |
UREK6120 | 12.0 | 26 | 83 | 12 | 6 | 50 | 70 |
UREK6140 | 14.0 | 26 | 83 | 14 | 6 | 50 | 70 |
UREK8160 | 16.0 | 32 | 92 | 16 | 8 | 50 | 70 |
UREK8180 | 18.0 | 32 | 92 | 18 | 8 | 50 | 70 |
UREK8200 | 20.0 | 38 | 104 | 20.0 | 8 | 50 | 70 |
