Description
Quiet Cooling
bada2010
BADA(바다) [bada] has a meaning of 'the sea' in Korean.
As though the sea is the source of "Harmonized and Balanced" for all natural objects, we want bada2010 to be a cooler that makes "Harmonized and Balanced" regarding thermal transfer, noise and tuning in PC system.
bada2010 is Low Noise-oriented CPU Cooler for high-end users who want use PC more quietly.
bada2010 runs almost noiselessly 1,000~1,500rpm in general situation.
Although bada2010 runs 2,100RPM, users can be satisfied with its Low Noise.
Available in PC Case of above 165mm width.
4-PIN PWM Rounded 92mm FAN Support.
Effective Cooling Performance with Low Noise (17~20dBA) at Low RPM (Max.2100rpm)
Silicon Fan Mount prevent vibration of FAN.
High quality Thermal Grease
Cooling performance similar to Big Tower Cooler
Various Socket compatibility
Applicable CPU
Socket Standards
Intel Socket LGA 2011, 1150, 1155, 1156, 1366, 775 CPUs / AMD Socket FM2, FM1, AM3+, AM3, AM2+, AM2 CPUs
Specification
| Product Name | bada2010 |
|---|---|
| Dimension | 135 × 115 × 95mm (H x W x L) |
| Weight | 521g |
| Material | Pure Copper and Pure Aluminum |
| Heat Pipes | Three 6mm diameter copper Heat Pipes(Sintered powder type) |
| Dissipation Area | 5,175 cm² |
| Thermal Grease | Color : Gray / Thermal Conductivity : 4.0W/mK / Specific Gravity : 2.6 / Operating Temperature : 0~150℃ / Capacity : 2g |
| Fan Dimension | 4-Pin Round 92mm PWM Fan |
| Fan Bearing Type | Long Life Rifle Bearing |
| Fan Speed (PWM Duty) | 1,000 - 2,100rpm ± 10% (0-100%) |
| Fan Noise Level(1) | 16-27.1 dBA |
note(1) : Measured at a point of 1m away from noise source.
Warranty
◦Warranty period is one year from the date of purchase and covers any defects of the product in materials or workmanship free of charge But, any damages or malfunction caused by customer faults shall be charged
