Applicable CPU

Socket Standards : Intel Socket 1155, 1156, 1366, 775CPUs / AMD Socket FM1, AM3, AM2+, AM2 CPUs

Thermal Design Power of CPU : Max 250 Watt

Components

Specification

Installation Condition

Case

Distance from motherboard to case side should be over 170mm.

For the case which has an Air Guide, it may have an interference with the heatsink fin, therefore install it with removing the Air Guide.

Height of parts on motherboard

For the case when any of the parts (chipset heatsink, RAM heatsink etc.) height is in excess of 53mm from the motherboard, it would not be able to be mounted. Please proceed with installation after checking these heights.

How to Install

Intel LGA 1366

Precautions

◦Please check whether it can be applied or not before using the product.
◦Check the components list and condition of the product before installation.
If any problem is found, contact your place of purchase to obtain a replacement.
◦Keep this product out of reach of children.
◦ThermoLab Co.,Ltd. is not responsible for any damages due to improper installation or improper use.
◦In order to maintain the proper airflow, the heatsink fin has been designed sharply. Be sure to be careful that your fingers do not get injured while you handling it.

Warranty

◦Warranty period is one year from the date of purchase and covers any defects of the product in materials or workmanship free of charge. But, any damages or malfunction caused by customer faults shall be charged.
