■ Specification
|
구분 |
PRE-ACTION VALVE |
DELUGE VALVE |
|||
|
SPV-71 |
SPV-72 |
SDV-71 |
SDV-72 |
||
|
WORKING |
1.5kg/cm² |
1.5kg/cm² |
1.5kg/cm² |
1.5kg/cm² |
|
|
APPLICABLE |
5~80℃ |
5~80℃ |
|||
|
INSTALLATION |
(VerticalㆍHorizontal) |
(VerticalㆍHorizontal) |
|||
|
MIN. OPERATION PRESSURE |
1.5kg/cm² |
1.5kg/cm² |
|||
|
CONNECTION |
KS 10K FF Flange |
KS 16K FF Flange |
KS 10K FF Flange |
KS 16K FF Flange |
|
|
HYDRO. |
20kg/cm²-2min |
32kg/cm²-2min |
20kg/cm² 2min |
32kg/cm² 2min |
|
|
METERIALS |
BODY, COVER |
GC 200 |
GCD 450 |
GC 200 |
GCD 450 |
|
SEAT RING |
BC 6 |
BC 6 |
|||
|
DIAPHRAGM |
N.B.R |
N.B.R |
|||
■ Dimension
|
PRESSURE |
SIZE |
SPACE |
VALVE FLANGE |
Weight |
||||||||
|
L |
L1 |
L2 |
L3 |
L4 |
H |
P.C.D |
øD |
t |
n-øh |
|||
|
10K |
80 |
271 |
165 |
190 |
200 |
150 |
365 |
150 |
185 |
22 |
8-19 |
25 |
|
100 |
314 |
180 |
220 |
220 |
180 |
465 |
175 |
210 |
24 |
8-19 |
45 |
|
|
125 |
320 |
235 |
250 |
240 |
210 |
475 |
210 |
250 |
24 |
8-23 |
66 |
|
|
150 |
380 |
220 |
260 |
280 |
220 |
500 |
240 |
280 |
26 |
8-23 |
80 |
|
|
16K |
80 |
274 |
200 |
210 |
205 |
168 |
380 |
160 |
200 |
24 |
8-23 |
27 |
|
100 |
316 |
200 |
246 |
205 |
196 |
480 |
185 |
225 |
26 |
8-23 |
48 |
|
|
125 |
355 |
280 |
248 |
250 |
200 |
500 |
225 |
270 |
26 |
8-25 |
68 |
|
|
150 |
384 |
280 |
275 |
290 |
210 |
570 |
260 |
305 |
28 |
12-25 |
82 |
|
