Product Specification
|
Measuring Radiation |
x, γ-ray |
|---|---|
|
Mesuring Sensitivity |
Cs-137, 0.01 μSv/h에 대해 10cpm 이상 |
|
Mesuring Range |
0.000 ~ 99.999 μSv/h (equivalent dose) |
|
Radiation Detection Part |
CsI (Tl) + silicone diode |
|
Energy Range |
150 keV ~ 1.25MeV |
|
Reading Error |
± 10% 이내 (Error on Cs-137 standard value) |
|
Direction Characteristics |
within ±20% on ± 90∘ |
|
Display of Radiation Doserate |
4 digit LCD segment bar graph (0.000~9.999 uSv/h) |
|
LCD Size |
Standrd of surface disclosure size (38mm X 35mm) |
|
Display response time |
35 seconds (the reading is displayed within 35 seconds after the switch on) |
|
Sampling time |
60 seconds |
|
Display interval |
The accumulated readings for 60 seconds (average of the variations) is displayed by 10 seconds interval. |
|
Display of Overdose |
Reading 99.999 number is turned on/off repeatedly |
|
Battery Alarm |
Alarm display is shown and the power os turned off automatically. |
|
Counting Sound (Buzzer) |
Buzzer occurs according to the counting (counting sound : about 75bB) |
|
Switch |
①Power Purpose ON/OFF ②Counting Sound Purpose ON/OFF |
|
Power |
Two 1.5Volt AA type (Alkaline battery), over 40 hours |
|
Case material |
ABS resin (Attach the wrist holding) |
|
Size |
length 143mm, width 57mm, thichness 28mm |
|
Weight |
less than 185g (including battery) |
※ Product features and design can be changed for better performance.
Applicable Field
Workers in Atomic Field, Around Atomic Facilities, National Defense System, Environmental Organization, Hospital, non-destructive industry, Laboratory, Educational uses for Elementary school, middle school and high school, Antiterrorism Organization and so on.
