Overview
- Summary
- RESOLUTION AIR is a specialized manufacturer of hygiene-specific proportional pinch valves, offering solutions for precise fluid control and sanitary fluid separation of liquids and gasesRESOLUTION AIR is a specialized manufacturer of hygiene-specific proportional pinch valves, offering solutions for precise fluid control and sanitary fluid separation of liquids and gases
- Key Products/Technologies
- The MPPV (Miniature Proportional Pinch Valve) series is a miniature proportional pinch valve that physically separates the valve from corrosive or high-purity process fluids, providing precise flow control similar to conventional proportional valvesThe MPPV (Miniature Proportional Pinch Valve) series is a miniature proportional pinch valve that physically separates the valve from corrosive or high-purity process fluids, providing precise flow control similar to conventional proportional valves
- The MPPV series integrates a stepper linear actuator and a custom piston for precise proportional control, with a locking lead screw design that requires power only when changing position, ensuring low power consumptionThe MPPV series integrates a stepper linear actuator and a custom piston for precise proportional control, with a locking lead screw design that requires power only when changing position, ensuring low power consumption
- The MPPV-2 model features a 0.125-inch (3.2mm) tube size, supports up to 100 PSI pressure, has a 0.5-second travel speed, and a lightweight design of 77gThe MPPV-2 model features a 0.125-inch (3.2mm) tube size, supports up to 100 PSI pressure, has a 0.5-second travel speed, and a lightweight design of 77g
- The MPPV-4 model is designed for a 0.250-inch (6.4mm) tube size, supports up to 50 PSI pressure, and has a 1-second travel speedThe MPPV-4 model is designed for a 0.250-inch (6.4mm) tube size, supports up to 50 PSI pressure, and has a 1-second travel speed
- The MPPV-6 model handles 0.375-inch tube sizes with up to 25 PSI and a 1.5-second travel speed, while the MPPV-8 model is for 0.500-inch tubes with up to 17 PSI and a 2-second travel speedThe MPPV-6 model handles 0.375-inch tube sizes with up to 25 PSI and a 1.5-second travel speed, while the MPPV-8 model is for 0.500-inch tubes with up to 17 PSI and a 2-second travel speed
- The HPPV (Hybrid Proportional Pinch Valve) series combines the precise fluid metering capabilities of a proportional valve with the sanitary fluid separation characteristics of a pinch valveThe HPPV (Hybrid Proportional Pinch Valve) series combines the precise fluid metering capabilities of a proportional valve with the sanitary fluid separation characteristics of a pinch valve
- The HPPV series utilizes a robust linear actuator capable of generating up to 50 lbs of pinch force, making it ideal for higher pressure systems and tube sizes up to 1.00 inch O.D.The HPPV series utilizes a robust linear actuator capable of generating up to 50 lbs of pinch force, making it ideal for higher pressure systems and tube sizes up to 1.00 inch O.D.
- The MPPV-EN Series is an IP65-rated proportional pinch control valve, and the MPPV-EN–PS Position Sensor Series integrates a compact position sensor for precise linear position feedbackThe MPPV-EN Series is an IP65-rated proportional pinch control valve, and the MPPV-EN–PS Position Sensor Series integrates a compact position sensor for precise linear position feedback
- The M-series and P-series are patent-pending proportional pinch valve designs that physically separate the valve from corrosive or high-purity process fluids while providing precise flow controlThe M-series and P-series are patent-pending proportional pinch valve designs that physically separate the valve from corrosive or high-purity process fluids while providing precise flow control
- The DRV-1 Stepper Motor Drive is a bipolar stepper motor drive for valve control, offering high flow resolution through 16 selectable microstep settingsThe DRV-1 Stepper Motor Drive is a bipolar stepper motor drive for valve control, offering high flow resolution through 16 selectable microstep settings
- Core Advantages
- Hygiene-specific design ensures no physical contact between the process fluid and the valve, minimizing contamination risks in corrosive or high-purity fluid handlingHygiene-specific design ensures no physical contact between the process fluid and the valve, minimizing contamination risks in corrosive or high-purity fluid handling
- High-precision proportional control capability enables fine and accurate flow regulation through a stepper linear actuator and custom piston, a significant technological advantageHigh-precision proportional control capability enables fine and accurate flow regulation through a stepper linear actuator and custom piston, a significant technological advantage
- Strong pinch force, generating 4 to 12 times higher pinch force compared to traditional solenoid pinch valves, ensures stable flow control even in high-pressure systemsStrong pinch force, generating 4 to 12 times higher pinch force compared to traditional solenoid pinch valves, ensures stable flow control even in high-pressure systems
- Low power consumption and position retention feature, due to the actuator's locking lead screw design, requires power only for position changes and maintains position during power loss, enhancing energy efficiency and system stabilityLow power consumption and position retention feature, due to the actuator's locking lead screw design, requires power only for position changes and maintains position during power loss, enhancing energy efficiency and system stability
- Robust design and high repeatability, with durable construction and tested performance, ensure long-term high repeatability, no leakage, and extended service life, signifying quality superiorityRobust design and high repeatability, with durable construction and tested performance, ensure long-term high repeatability, no leakage, and extended service life, signifying quality superiority
- Versatility in applications, offering various series to meet diverse tube sizes and pressure requirements from miniature and handheld equipment to high-pressure systems, demonstrates a strong product portfolioVersatility in applications, offering various series to meet diverse tube sizes and pressure requirements from miniature and handheld equipment to high-pressure systems, demonstrates a strong product portfolio
- Target Industries
- Chemical Mixing/DispensingChemical Mixing/Dispensing
- Clinical or Chemical AnalysisClinical or Chemical Analysis
- Blood Handling/AnalysisBlood Handling/Analysis
- Vending MachinesVending Machines
- Dosage SystemsDosage Systems
- Lab AnalysisLab Analysis
- Medical Device and Life SciencesMedical Device and Life Sciences
- Biochemical/Bioprocess EngineeringBiochemical/Bioprocess Engineering
- BioreactorsBioreactors
- MicrofluidicsMicrofluidics
- Gene TherapyGene Therapy
- Fill and Finish ProcessesFill and Finish Processes
- Filtration and Sterilization SystemsFiltration and Sterilization Systems
- Food and BeverageFood and Beverage
- Major Markets
- United States (Company started in the US)United States (Company started in the US)
- Certifications/Patents
- M-series and P-series proportional pinch valve designs are patent pending technologiesM-series and P-series proportional pinch valve designs are patent pending technologies
- MPPV (Miniature Proportional Pinch Valve) technology is a patent-pending valve technologyMPPV (Miniature Proportional Pinch Valve) technology is a patent-pending valve technology
- The MPPV-EN–PS Position Sensor Series expands the portfolio of patented Proportional Pinch ValvesThe MPPV-EN–PS Position Sensor Series expands the portfolio of patented Proportional Pinch Valves
