Overview
- Summary
- Ph-instruments is a specialized company in high vacuum pressure measurement systems utilizing Spinning Rotor Gauge (SRG) technology [6, 7]. The company provides solutions tailored for industrial high vacuum applications, research, and scientific fields [6, 7]. Key product lines include the Dositorr SRG transducer, VIM-2 mobile SRG system, and ION Check [2, 5, 15]. Robust, accurate, reliable, contactless, and long-term stable vacuum measurement technology represents its core competence [6, 7].Ph-instruments is a specialized company in high vacuum pressure measurement systems utilizing Spinning Rotor Gauge (SRG) technology [6, 7]. The company provides solutions tailored for industrial high vacuum applications, research, and scientific fields [6, 7]. Key product lines include the Dositorr SRG transducer, VIM-2 mobile SRG system, and ION Check [2, 5, 15]. Robust, accurate, reliable, contactless, and long-term stable vacuum measurement technology represents its core competence [6, 7].
- Key Products/Technologies
- Spinning Rotor Gauge (SRG) Technology: A direct physical measurement principle determining pressure by measuring the deceleration rate of a magnetically levitated, freely rotating stainless steel ball [1, 4]. This method calculates pressure through momentum transfer from gas molecule collisions [1, 4]. It ensures non-contact measurement without any interference to the vacuum system [7, 14].Spinning Rotor Gauge (SRG) Technology: A direct physical measurement principle determining pressure by measuring the deceleration rate of a magnetically levitated, freely rotating stainless steel ball [1, 4]. This method calculates pressure through momentum transfer from gas molecule collisions [1, 4]. It ensures non-contact measurement without any interference to the vacuum system [7, 14].
- DosiTorr SRG Transducer: An autonomously operating process manometer based on SRG technology [2, 4]. It offers a measurement range from 10 mbar to 5x10^-7 mbar, with a high accuracy of 1% in the range of 0.1 to 1x10^-6 mbar [2, 4]. Key features include long-term stability with less than 1.5% drift per year and a stainless-steel sensor insensitive to corrosion and deposition [2]. Magnetic shielding and an integrated temperature sensor provide a stable measurement environment [2].DosiTorr SRG Transducer: An autonomously operating process manometer based on SRG technology [2, 4]. It offers a measurement range from 10 mbar to 5x10^-7 mbar, with a high accuracy of 1% in the range of 0.1 to 1x10^-6 mbar [2, 4]. Key features include long-term stability with less than 1.5% drift per year and a stainless-steel sensor insensitive to corrosion and deposition [2]. Magnetic shielding and an integrated temperature sensor provide a stable measurement environment [2].
- VIM-2 mobile SRG system: A stationary and mobile, battery-operated, highly accurate, and long-term stable vacuum pressure gauge [5]. It allows for the separation of the sensor and the measuring head/electronics, enabling cost-effective checking of static vacuums [5]. The system provides a measurement range of 10 mbar to 5x10^-7 mbar, achieving 1% accuracy between 0.1 and 1x10^-6 mbar [5].VIM-2 mobile SRG system: A stationary and mobile, battery-operated, highly accurate, and long-term stable vacuum pressure gauge [5]. It allows for the separation of the sensor and the measuring head/electronics, enabling cost-effective checking of static vacuums [5]. The system provides a measurement range of 10 mbar to 5x10^-7 mbar, achieving 1% accuracy between 0.1 and 1x10^-6 mbar [5].
- ION Check: An SRG technology-based ion gauge calibration and comparison system [15]. This complete solution for calibrating and comparing high vacuum gauges utilizes an SRG as a certified, accurate, and long-term stable pressure standard [15]. It includes an oil-free and vibration-insulated high vacuum system, a gas dosing unit, and hardware/software for readout and calibration of analog output vacuum gauges [15].ION Check: An SRG technology-based ion gauge calibration and comparison system [15]. This complete solution for calibrating and comparing high vacuum gauges utilizes an SRG as a certified, accurate, and long-term stable pressure standard [15]. It includes an oil-free and vibration-insulated high vacuum system, a gas dosing unit, and hardware/software for readout and calibration of analog output vacuum gauges [15].
- Core Advantages
- Unique SRG Technology: A direct and fundamental measurement principle without electrical feedthroughs, heat transfer, or mechanical effects that could influence vacuum conditions [4, 7, 14]. This ensures unparalleled long-term stability and reproducibility [1, 7].Unique SRG Technology: A direct and fundamental measurement principle without electrical feedthroughs, heat transfer, or mechanical effects that could influence vacuum conditions [4, 7, 14]. This ensures unparalleled long-term stability and reproducibility [1, 7].
- High Accuracy and Long-Term Stability: The DosiTorr offers 1% accuracy in the high vacuum range and less than 1.5% drift per year [2, 4]. SRG technology maintains intrinsic accuracy comparable to transfer standards, eliminating the need for recalibration [1, 7].High Accuracy and Long-Term Stability: The DosiTorr offers 1% accuracy in the high vacuum range and less than 1.5% drift per year [2, 4]. SRG technology maintains intrinsic accuracy comparable to transfer standards, eliminating the need for recalibration [1, 7].
- Robust and Clean Sensor Design: A simple stainless-steel ball sensor design, unaffected by corrosive environments, contamination, or aging, making it ideal for high-purity processes [2, 4, 5]. The sensor can be permanently welded to the vacuum system for enhanced durability [5].Robust and Clean Sensor Design: A simple stainless-steel ball sensor design, unaffected by corrosive environments, contamination, or aging, making it ideal for high-purity processes [2, 4, 5]. The sensor can be permanently welded to the vacuum system for enhanced durability [5].
- Autonomous and User-Friendly Operation: The DosiTorr operates autonomously, allowing direct integration into various systems [4]. The VIM-2 is battery-operated and user-friendly, with remote control capabilities via a Bluetooth app for maximum convenience [5].Autonomous and User-Friendly Operation: The DosiTorr operates autonomously, allowing direct integration into various systems [4]. The VIM-2 is battery-operated and user-friendly, with remote control capabilities via a Bluetooth app for maximum convenience [5].
- Versatile Sensor Application: The two-part sensor/readout design enables the use of a single measurement head for multiple sensors, offering cost-effectiveness [7, 14]. This provides flexible application across diverse scenarios [7, 14].Versatile Sensor Application: The two-part sensor/readout design enables the use of a single measurement head for multiple sensors, offering cost-effectiveness [7, 14]. This provides flexible application across diverse scenarios [7, 14].
- Extensive Expertise and European Production: Founded in 2018/19 by Peter Hofmann, drawing on 19 years of experience in vacuum technology [6, 11]. Products are developed and produced in Germany and Austria, meeting the highest quality standards for reliability [2, 7].Extensive Expertise and European Production: Founded in 2018/19 by Peter Hofmann, drawing on 19 years of experience in vacuum technology [6, 11]. Products are developed and produced in Germany and Austria, meeting the highest quality standards for reliability [2, 7].
- Target Industries
- Industrial High Vacuum applications [6, 7]Industrial High Vacuum applications [6, 7]
- Research and Science (laboratory, scientific research) [7]Research and Science (laboratory, scientific research) [7]
- Vacuum Insulation (VI): cryogenic liquid gas tanks, high-temperature batteries, solar collectors, dewars, refrigerators, cooled superconducting magnets and wires [5, 12]Vacuum Insulation (VI): cryogenic liquid gas tanks, high-temperature batteries, solar collectors, dewars, refrigerators, cooled superconducting magnets and wires [5, 12]
- Vacuum Processing [5, 14]Vacuum Processing [5, 14]
- R&D and Quality Control (QC) for vacuum protected devices and getter development: lamp manufacturing, vacuum interrupters, electron beam applications (X-ray tubes, e-beam evaporation, photon multipliers, magnetrons, electron microscopes) [16, 19]R&D and Quality Control (QC) for vacuum protected devices and getter development: lamp manufacturing, vacuum interrupters, electron beam applications (X-ray tubes, e-beam evaporation, photon multipliers, magnetrons, electron microscopes) [16, 19]
- Calibration applications for high vacuum manometers (e.g., ion gauges) [2, 3, 15]Calibration applications for high vacuum manometers (e.g., ion gauges) [2, 3, 15]
- Process analytics and process measurement technology [9]Process analytics and process measurement technology [9]
- Major Markets
- Austria, Germany, United Kingdom, France, BeneluxAustria, Germany, United Kingdom, France, Benelux
- Certifications/Patents
- Products developed and produced in Germany and Austria meet the highest quality standards for measurement accuracy, sustainability, and reliability [2, 7].Products developed and produced in Germany and Austria meet the highest quality standards for measurement accuracy, sustainability, and reliability [2, 7].
- A patent application by Ph-instruments GmbH inventors Ferdigg, Raffael and Hofmann, Peter, concerning a pressure measuring device (10) with a temperature-controlled or temperature-adjustable pressure measuring unit (11) designed to prevent and/or remove deposits during application processes [25]. This patent includes IPC classifications related to vacuum gauges (G01L 21/24) [25].A patent application by Ph-instruments GmbH inventors Ferdigg, Raffael and Hofmann, Peter, concerning a pressure measuring device (10) with a temperature-controlled or temperature-adjustable pressure measuring unit (11) designed to prevent and/or remove deposits during application processes [25]. This patent includes IPC classifications related to vacuum gauges (G01L 21/24) [25].
- Spinning Rotor Gauge (SRG) is recognized as a highly accurate and long-term stable transfer standard [15].Spinning Rotor Gauge (SRG) is recognized as a highly accurate and long-term stable transfer standard [15].
