Mostar Co., Ltd. is a B2B company specializing in the manufacturing of micro coaxial cables and RF coaxial cables, producing various cable assembly products. The company demonstrates capabilities in supplying products to the global market through import and export trade activities of electrical and electronic materials and components. A technology-driven enterprise fulfilling diverse industry demands with customized solutions.

마이크로 동축 케이블 및 RF 동축 케이블을 전문적으로 제조하며, 다양한 케이블 어셈블리 제품을 생산하는 B2B 기업. 전기·전자 소재 및 부품의 수출입 무역 활동을 통해 글로벌 시장에 제품을 공급하는 역량. 고객 맞춤형 솔루션 제공으로 다양한 산업 분야의 요구를 충족시키는 기술 기업.

Coupling	Threaded
Shell material	PC, Nylon66 Fire resistance : V-0
Insert material	PPS, Max temp. 260℃
Contact material	Brass with gold plating
Termination	Solder : SP13, SP17, SP21, SP29 Crimp : SP17, SP21, SP29 Screw : SP21, SP29 (Ø2.5, Ø3, Ø3.5mm contact)
Cable outer diameter range	SP11 : 4~6.5mm SP13 I : 4~6.5mm, II : 5~8mm SP17 : 6~10mm SP21 I : 4.5~7mm, II : 7~12mm SP29 : 13~16mm
IP rating	IP68
Mating cycle	500
Temperature range	-40 ~ +85℃
Insulation resistance	2000MΩ
Rated Current and Voltage	Rated Current : Up to 60A Rated Voltage : Up to 500V
Certification	CE, ROHS approval
