Manufacturer
Libertron
Product Type
Machine
Brand
-
SKU
45836
Product Name
-
Model Name
EDA-Mod 7V2000T
Size
-
Weight
-
Product Details
| Item | Specification | Details |
| FPGA | XC7V2000T-FLG1925C | Logic cell: 1,954,560 |
| Memory | DDR3 SO-DIMM | Density: 2GByte (up to 8GByte) |
| BPI Configuration Flash | Density: 64MByte (JS28F512P30TF) | |
| Async-SRAM | Density: 2MByte / Access time: 15ns | |
| Connectivity | UART | UART 1-Port (RS232C) |
| Clock | User Clock | Single ended: 100MHz (Main) Differential: 125MHzx1ea ,200MHz x1ea User clock |
| VITA 57 based FMC Total: 160 I/Os - 8 GTXs Transceiver / 4 GTXs Clocks - 2 Differential clock |
||
| Expansion Port | FMC Port | Exp_X, Y, Z Total: 612 I/Os (8 GTXs Transceiver, 4 GTXs Clock) |
| Expansion port | 2CH (Resolution: 12Bit) | |
| AMS ADC | XADC Port | User LED 8-bits |
| LED | Discrete LED | +5V(AC to DC Adapter appllied) |
| Switches | DIP Switch, Push Switch | Reset Switch 1 Input |
| Reset Switch | ||
| User Select I/O | 1.2V, 1.35V,1.5V,1.8V (Differential I/O support) | |
| Power | DC-Input | DC +5V |
| Size | H x V x D | 180mm x 155mm x 40mm |
