FIXED FOCUS MODELS

ELECTRONIC FOCUS CONTROL MODEL

 Dimensions

 Straight optic
50 x 25 x 45 mm
(1.97x0.98x1.77 in)

 Right angle optic
54 x 32 x 45 mm

(2.13x1.26x1.77 in)

61 x 25 x 45 mm
(2.40 x 0.98 x 1.77 in)

 Weight

 204 g. (7.2 oz.) with cable

 237 g. (8.4 oz.) with cable

 Case material

 Aluminum, plastic protective window cover

 Operating temperature

 0° to 50° C (32 to 122 °F)

0° to + 45 °C (32 to 113°F)

 Storage temperature

-20 to 70 °C (-4 to 158 °F)

 Protection class

 IP65

 Esd safe

 YES, with ESD Safe front cover accessory

 Yag laser protection

YES, with YAG cut filter accessory

 Power supply

Standard: 10 VDC to 30 VDC

 Power consumption

0.4 to 0.15 A, 4.5 W max

 Sensor

Image Resolution 780 x 480 WVGA - CMOS global shutter

 Frame rate

60 frames/s

 Optical focus control

 Fixed

Variable, Electronic focus control

 Aiming system

 Blue Ring LED system

Dual laser pointer (CDRH/IEC Class II)

 Readable symbologies

1D Codes: all standard 1 dimensional symbologies
2D Codes: Data Matrix, QR Code, Micro QR, Maxicode, Aztec
Postal Codes: Royal Mail, Japan Post, Planet, Postnet and many more

 Embedded communication  interfaces

Ethernet 10/100: EtherNet/IP, PROFINET, TCP/IP, UDP, FTP, MODBUS TCP
Serial RS232/RS422/RS485 up to 115.2 Kbit/s + Aux RS232

 Reader networking

Datalogic ID-NET™

 Connectivity modes

Master/Slave, Ethernet point to point

 Digital inputs

2 opto-isolated. Polarity insensitive and SW Programmable.

 Digital outputs

 2 SW programmable, opto-coupled

 Programming method

Windows™ based SW (DL.CODE™) via serial, USB and Ethernet

 User interface

X-PRESS™, Embedded Human Machine Interface
Beeper, Push Button, 7 LEDs (Status, Comm. , Trigger, Good Read, Ready, Power on, Network)

 Code quality metrics

 AIM DPM, ISO/IEC 15416
