Axis-tool number display
- DC24V input voltage
- Information display function
- Improved operator convenience
- Shortening the setting time
- Operation mistake prevention
Features
Outer dimension
Specification
Contects | Unit | Specification |
---|---|---|
Size | – | 112(L)x92(W)x 29.5 |
Input voltage | V | 24 ± 10% |
Consumption power | W | (Max)5W |
Input current | A | (Max)0.20 |
Display | – | FND(Letter(1.23″)*1, Number(0.8″)*2) |
CUP | ATMEGA128AU | |
DIO outside input signal | Axis Data(4bit) Tool No data(7bit) | |
Weight | – | 270g±0.5% |
Operating temp | – | -10℃ ~ 60℃ |
Storage temp | – | -40℃ ~ 80℃ |
System application
Axis-tool number display (PUMA GT3100 applied)
The information display inside the equipment makes it easy to check the currently selected axis and tool number in the handle mode, thereby improving the hassle of the user turning their head to check the control panel every time.
