KNTEC

KNTEC

Iron(Fe) Analyzer

Model

Series

Products


Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

The Republic of Korea


Description

Convenient maintenance

ㆍEasy tube replacement & disassembly

ㆍNo defect du to simplified structure

ㆍData storage function (USB)

7" Color LCD Monitor

Display of data trend

Alarm function for lack of reagents or sample

Automatic calibration by standard solution

Multichannel operation(1~3ch)

Applications

ㆍPower plants, Chemical plants etc.

ㆍIron ion(Fe) monitoring of the industrial boiler system



Technical Specifications

Model AI-300

Measure principle

Colorimetric Method

Measuring Range

0 ~ 300 ppb

Display

0.1 ppb

Accuracy

±2% of FS

Response Time

12~15 min

Sample Pressure

1~5 Bar

Sample Temp.

5 ~ 45 ℃

Sample Flow

200~500 ml /min

Sample Connections

Inlet 6mm / Outlet 10mm

Reagent Consumption

30 days (A 5L, B 2L, C 3L, STD/2L)

Data Output

4 ~ 20 mA 2 ea, Alarm 2 ea

AUX ports

DI(2), DO(2), Option(AI, AO)

Dimensions

400W X 500H X 200D (Flush type, Wall Mount type),
700W X 1800H X 400D (Self-standing type)

Degree of Protection

IP65(NEMA 4x): Electronics, IP55(NEMA 4): Wet part

Power

100~240 VAC (50/60 Hz)
