HYUNDAI WIA

HYUNDAI WIA

Compact T/C

Model

Series

CNC Turning Center


Transaction Process

Please contact the manufacturer/supplier.

Payment

Contact the manufacturer/supplier.

Delivery

Contact the manufacturer/supplier.

Shipment

Contact the manufacturer/supplier.

Origin

Korea (Republic of)


Description

Features

- 45° slanted one-piece rigid bed structure

- Minimal thermal distortion

- Machine structure designed to maximize productivity

- Best in class rapid traverse rate : 30m/min

- The most reliable high speed servo turret : 0.1sec/step

- Environmental friendly, separate coolant and lubrication design

- Compact design, able to install within a limited space.

- Ergonomic design allows convenient access to chuck and tools



Specifications

Description

Unit

E160A

E160LA

E160LMA

Max Turning Dia

mm

280

280

190

Max Turning Length

mm

300

510

450

Chuck Size

inch

6″

6″

6″

Driving Method

-

Belt

Belt

Belt

Spindle RPM

r/min

6,000

6,000

6,000

Spindle Output

kw

11/7.5

11/7.5

15/11

Spindle Torque

N.m

35.8/70

35.8/70

52.5/95.5

Travel(X/Z)

mm

165/330

165/530

165/460

Rapid Travel(X/Z)

m/min

30/30

30/30

30/30

Slide Type

-

LM

LM

LM

No. of Tools

EA

12

12

12

Tool Size

mm

20/32

20/32

20/32

Milling Tool Speed

r/min

-

-

4,500
