Features of Series

• The performance of energy saving is more than top-runner standard value
• Significant decrease of emission of carbon dioxide
• The energy saving effect is greatly different based on the load factor
  Because of the low no-load loss and extremely low standby power requirement, the high energy saving effect that suitable for the reality is created.
• Reasons for super energy saving and highly effectiveness
  Amorphous is exceptional material
• Environmental-friendly transformers
  Recycling concept of amorphous

Specification

No. of phases	Rating Capacity (kVA)	Frequency	Voltage Specification		Connection	Standard
			Primary (V)	Secondary (V)
6kV Standard Model 200V class
Single	300, 500	50 or 60 only	F6,750-R6,600-F6,450-F6,300-6,150	210-105	For single/ three only	JEC 2200-1995 JEM 1482-2005
Three	300、500			210
	750～2,000
6kV Standard Model 400V class
Three	300～3,000	50	F6,750-R6,600-F6,450-F6,300-6,150	420-242	(The second side with neutral point)	JEC 2200-1995 JEM 1482-2005
	300～3,000	60		440-254
6-3kV Common Model 200V class
Single	300, 500	50 or 60 only	F6,750-R6,600-F6,450-F6,300-6,150 F3,375-R3,300-F3,225-F3,150-3,075	210-105	For single/ three only	JEC 2200-1995 JEM 1482-2005
Three	300、500			210
	750～2,000

* The numerical values of the voltage and the rating capacity, etc. of the specification table are Japanese specifications. Please ask us about the specifications for foreign countries.
