  • ELECTRONIC DEVICE SOLUTION

    ELECTRONIC DEVICE SOLUTION

    High Power Amplifier MMIC
    Model
    -
    Series
    Device

    Product Description

    High Power Amplifier MMIC

    16-Channel Transceiver Module X Band HPA MMIC die



    PRODUCT DESCRIPTION

    ㆍGaN HPA MMIC Production and Performance Verification



    PRODUCT STANDARD

    CATEGORY PERFORMANCE
    Frequency X-band (9 GHz ~ 10 GHz)
    Output power (dBm) 44.8 or more
    Output power (W) 30 or more
    Small signal gain (dB) 30 or more
    Drain eff. (%) 40 or more
    PAE (%) 40 or more
    Drain voltage (V) 28
    Gate voltage (V) -2.3

    Product List

    Device

    High Power Amplifier MMIC

    Components

    Custom DC Connector
    Custom RF Connector
    Filter Embedded Connector

    Modules

    Transmitter Drive Amplifier Module for radar
    Radar Test Equipment
