MODEL

DST-MP

DST-MP

DST-MP

DST-MP

UNIT

TONNAGE

CLAMP MAX

200

250

200

250

ton

TRANSFER MAX

7

7

7

7

ton

DIMENSION

DIE SPACE

820 x 940

820 x 940

820 x 940

820 x 940

mm

DAY LIGHT

750

750

750

750

mm

OVERALL HEIGHT

2,700

2,700

3,050

3,050

mm

FLOOR SPACE

1,850 x 500

1,850 x 500

2,050 x 1700

2,050 x 1700

mm

PLUNGER THREAD

M24 x 3P

M24 x 3P

M24 x 3P

M24 x 3P

mm/inch

EJECTOR ROD DIA

23

23

23

23

mm

WORKING PRESSURE

CLAMP SYSTEM MAX

210

210

210

210

Kg / ㎠

TRANSFER SYSTEM MAX

120

120

120

120

Kg / ㎠

STROKE

CLAMP

300

300

300

300

mm

TRANSFER

320

320

320

320

mm

EJECTOR

0 ~ 70

0 ~ 70

0 ~ 70

0 ~ 70

mm

SPEED

CLAMP FAST

110 ~ 130

110 ~ 130

110 ~ 130

110 ~ 130

mm / sec

CLAMP SLOW

5 ~ 20

5 ~ 20

5 ~ 20

5 ~ 20

mm / sec

CLAMP RETURN FAST

100 ~ 120

100 ~ 120

100 ~ 120

100 ~ 120

mm / sec

CLAMP RETURN SLOW

5 ~ 20

5 ~ 20

5 ~ 20

5 ~ 20

mm / sec

TRANSFER FAST

120 ~150

120 ~150

120 ~150

120 ~150

mm / sec

TRANSFER SLOW

5 ~ 20

5 ~ 20

5 ~ 20

5 ~ 20

mm / sec

TRANSFER RETURN

200 ~ 250

200 ~ 250

200 ~ 250

200 ~ 250

mm / sec

CURRENT REQUIRMENTS

MOTOR POWER

7.5

11

7.5

11

KW

PUMP MODEL

PV2R12-10-33

PV2R12-10-41

PV2R12-10-33

PV2R12-10-41

ℓ/ MIN

ELECTRIC HEATER

2 x12

2 x12

2 x12

2 x12

KW

VACUUM SYSTEM

MODEL

.

.

3.7

3.7

KW

MOTOR

.

.

70 ~ 76

70 ~ 76

Mbar
