Featuresย
- Fully automatic NC control and touch screen typeย
- Extension of saw blade life by using high precision reducerย
- Precise cutting length by servo motorย
- Ten cut off lengths programmableย
- Display of error types and their solutionsย
- Head moving by ball screwย
- Suitable for cold forging workย
- Material size auto measuringย
- Motor driven chip brush unitย
- Sawhead servo feedingย
Standard Accessariesย
- Auto Feeder 6Mย
- Steel belt type chip conveyorย
- Sawhead servo feedingย
Optional Accsessariesย
- Blade cooling device(cold air gun)ย
- Mist cleanerย
- Workpiece out-auto feeder
ย
Specifications
MODEL |
DT-130 |
|
Operating Method |
NC System & Touch Screen |
|
Saw Blade |
ร420ร2.7T / 3.0T |
|
Cutting Capacity |
ร50~130 |
|
Max. feed Stroke |
750mm |
|
Min. Remnants |
70mm |
|
Saw Blad Speed |
50~140rpm |
|
Motor |
Drive |
15.0kw |
Hydraulic System |
2.2kw |
|
Feed System |
A/C Servo Motor |
|
Saw Cooling |
Compressed Air and Misting Oil | |
Weight |
5,200kg |
|
Floor Space (WรHรL) |
2940ร1900ร6750mm |
