  • DAEKYOUNG TECH

    Impact Tester
    Model
    -
    Series
    Material Tester

    Product Description


    DAEKYOUNG TECH Impact Tester

    International standard - Dupont Drop Tester.


    DAEKYOUNG TECH Impact Tester  1

    Customized mobile phone drop impact tester.

    - Free fall
    - Drop height : adjustable
    - Base material : adjustable (steel / wood / stone)


    DAEKYOUNG TECH Impact Tester  2


    DAEKYOUNG TECH Impact Tester  3

    Drop impact tester for helmet.

    - Test height : adjustable
    - Drop weight : adjustable


    DAEKYOUNG TECH Impact Tester  4

    Model number : DTI-604

    Box drop impact tester
    On the corner and edge drop test is available.


    DAEKYOUNG TECH Impact Tester  5

    Model number : DTI-603B

    Charpy impact tester.

    - Manufactuered in compliance with ASTM Standard
    - Variety of capacity products available by customer's needs.
    - PC based control
    - Automatic breaking & reset system
    - Built-in 32 bit data acquisition controller with 24 bit resolution.

    - Real time hammer angle indication.
    - Impact strength indication.
    - Average impact strength value out put (Printing)
    - Automatic Excel program conversion function.
    - Patented pneumatic breaking system


    DAEKYOUNG TECH Impact Tester  6

    Model number : DTI-602A

    Manual low capacity Izod impact tester.

    - Capacity : 3J, 6J, 15J
    - Max. set angle : 120 deg.
    - Weight of hammer : 2.44 kg
    - Dimension : 560 x 400 x 450 mm
    - Weight : about 50 kg


    DAEKYOUNG TECH Impact Tester  7

    Model number : DTI-601

    Manual low capacity Izod impact tester.

    - Capacity : 3J, 6J, 15J
    - Max. set angle : 120 deg.
    - Weight of hammer : 2.44 kg
    - Dimension : 560 x 400 x 450 mm
    - Weight : about 50 kg


    DAEKYOUNG TECH Impact Tester  8

    This machine is customized impact tester.


    DAEKYOUNG TECH Impact Tester  9

    Customized seat frame impact tester.
