AMS-SERIES
The excellent cooling ability, Superior durability, Extending system life by built-in safety devices
CHARACTERISTIC
- Preventing degradation of cooling ability when indoor temperature is above 27 degrees, the environment can be comfortable by separating and installing Cooler outside.
- For the place of no Ventilation, Less production, and higher heat, separated one is suitable.
- It provides us with deliberate temperature and wide range of temperature from 15 degrees to 25 degrees by touching only once.
- In terms of simple design and compact size, It is possible to install in the small places.
- This item is needed outdoor unit facilities 9including product) when it using.
FLOW DIAGRAM
Ref. Gas Line
Water Line
- ACompressor
- BOil Separator
- CAircoolde condenser
- DReceiver tank
- EFilter drier
- FSight glass
- GSolenoid Valve
- HExpansion valve
- IAccumulator
- JEvaporator
- KWater Supply
- LWater Return
- MDrain Valve
- NDigital Pressure
STANDARD SPECIFICATION
| Item | DH-5AMS | DH-7.5AMS | DH-10AMS | DH-15AMS | DH-20AMS | |
|---|---|---|---|---|---|---|
| Refrigerator Capacity | 5 | 7.5 | 10 | 15 | 20 | |
| Port Size(Inlet/Outlet) | 32A(1-1/4") | 40A(1-1/2") | 50A(2") | |||
| Cooling Water Port Size | 25A(2") | 32A(1-1/4") | 40A(1-1/2") | 50A(2") | 65A(2-1/2") | |
| Cooling Medium | Clean Water | |||||
| Refrigerant | R-22(R-407C) | |||||
| Compressor Output(kW) | 3.75 | 5.5 | 7.5 | 11.25 | 15 | |
| Cooling Capacity(at 20℃,Kcal/h) | 12,000 | 18,000 | 25,000 | 37,000 | 50,000 | |
| Circulation Pump Output(Kw) | NONE | |||||
| Evaporator | Shell and tube type (STS 304) | |||||
| Water Tank(ℓ) | NONE | |||||
| Dimension(L x W x H) | 1,000 x 600 x 750" | 1,350 x 750 x 750" | 1,350 x 750 x 750" | 1,600 x 900 x 900" | 2,070 x 900 x 900" | |
| Dimension(L x W x H) | 925 x 950x 1,775" | 925 x 855 x 1,023" | 1,576 x 900 x 810" | 1,756 x 943 x 910" | 2,226 x 904 x 910" | |
| Total Power Consumption | 4.15 | 6.35 | 8.3 | 12.25 | 16.5 | |
| Power(v) | AC 3Φ 220/380/440V 50/60Hz | |||||
※ All the details can be changed without any notice with the products developed.
(Option : ±0.1℃ temperature control, Ultralow-temperature Chiller(-80℃), Customized order)
PURPOSE OF USE
For Sauna's cold water, Swimming fool, Ice room, Custom made solution
