Overview
- Summary
- BK Mikro is a company specializing in reliable tool and process monitoring systems, detecting the smallest deviations from nominal conditions to ensure stable control of production processes. This minimizes waste, production downtime, and costly consequential damages. The company is part of Schubert System Elektronik GmbH, a member of the globally active Schubert Group, employing approximately 1,000 people.BK Mikro is a company specializing in reliable tool and process monitoring systems, detecting the smallest deviations from nominal conditions to ensure stable control of production processes. This minimizes waste, production downtime, and costly consequential damages. The company is part of Schubert System Elektronik GmbH, a member of the globally active Schubert Group, employing approximately 1,000 people.
- Key Products/Technologies
- The main product line comprises tool and process monitoring systems consisting of control units, scanners, and accessories. Control units are available in three types: Basic for simple monitoring functions, Premium for monitoring up to 512 tools or functions, and Premium with Fieldbus for integration with CNC software via fieldbus masters like Profibus or DeviceNet. A micro-computer control unit initiates scanner movement and compares measurement results with defined parameters, transmitting 'OK' or 'KO' signals to the machine control unit.The main product line comprises tool and process monitoring systems consisting of control units, scanners, and accessories. Control units are available in three types: Basic for simple monitoring functions, Premium for monitoring up to 512 tools or functions, and Premium with Fieldbus for integration with CNC software via fieldbus masters like Profibus or DeviceNet. A micro-computer control unit initiates scanner movement and compares measurement results with defined parameters, transmitting 'OK' or 'KO' signals to the machine control unit.
- Scanners are offered in various performance classes, including rotary scanners for orthogonal/axial scanning and linear scanners for stroke movements. The TK7A/TK7RL models are suitable for the price-sensitive segment, offering fast and simple monitoring, ideal for confined spaces and small tool diameters (0.1mm) with a 180° travel in 0.4 seconds. The TK8A model is designed for precise scanning results with relatively short cycles and a larger distance to the object, providing an accuracy of ±0.15° and a measuring range up to 380 mm.Scanners are offered in various performance classes, including rotary scanners for orthogonal/axial scanning and linear scanners for stroke movements. The TK7A/TK7RL models are suitable for the price-sensitive segment, offering fast and simple monitoring, ideal for confined spaces and small tool diameters (0.1mm) with a 180° travel in 0.4 seconds. The TK8A model is designed for precise scanning results with relatively short cycles and a larger distance to the object, providing an accuracy of ±0.15° and a measuring range up to 380 mm.
- The TK91A/TK91UNI models are specialized for scanning long tools and detecting the smallest deviations, offering a high accuracy of ±0.05°. The TK94A/TK94RL models are robust and high-speed, ideal for applications requiring very durable scanners with extremely short scanning cycles (180° travel in 0.25 seconds) and tool diameters as small as 0.5 mm. The TK9LIN50 model is used for linear and precise scanning, featuring a 50mm measuring range and repeatability up to 0.05 mm. The TK96A/TK96RL models are compact and dynamic solutions for the smallest and narrowest process zones, featuring a stainless steel body and supporting tool diameters down to 0.1 mm.The TK91A/TK91UNI models are specialized for scanning long tools and detecting the smallest deviations, offering a high accuracy of ±0.05°. The TK94A/TK94RL models are robust and high-speed, ideal for applications requiring very durable scanners with extremely short scanning cycles (180° travel in 0.25 seconds) and tool diameters as small as 0.5 mm. The TK9LIN50 model is used for linear and precise scanning, featuring a 50mm measuring range and repeatability up to 0.05 mm. The TK96A/TK96RL models are compact and dynamic solutions for the smallest and narrowest process zones, featuring a stainless steel body and supporting tool diameters down to 0.1 mm.
- Scanning wands are available in various lengths and types, are replaceable, with a standard length of 165mm, a diameter of 1.2mm, and extendable up to 610mm. Specially hardened HSS steel wands are also available for rotating tools. The system utilizes a servo motor and encoder to 'learn' tool/object positions, continuously monitoring tool integrity and position in real-time throughout the machine cycle.Scanning wands are available in various lengths and types, are replaceable, with a standard length of 165mm, a diameter of 1.2mm, and extendable up to 610mm. Specially hardened HSS steel wands are also available for rotating tools. The system utilizes a servo motor and encoder to 'learn' tool/object positions, continuously monitoring tool integrity and position in real-time throughout the machine cycle.
- Core Advantages
- Reliability and Precision: The system detects the smallest deviations from nominal conditions, ensuring stable control of production processes, preventing defective production and consequential damages, and offering high repeatability and accuracy.Reliability and Precision: The system detects the smallest deviations from nominal conditions, ensuring stable control of production processes, preventing defective production and consequential damages, and offering high repeatability and accuracy.
- Robustness and Durability: Proven scanners for extreme conditions, featuring double-lipped special seals that make them impervious to aggressive coolants, dust, and chips, with most scanners boasting an IP67 protection rating.Robustness and Durability: Proven scanners for extreme conditions, featuring double-lipped special seals that make them impervious to aggressive coolants, dust, and chips, with most scanners boasting an IP67 protection rating.
- Versatility and Flexibility: A wide range of scanner and control unit combinations allows for application in diverse scenarios, easy individual system retrofitting, and the provision of Basic, Premium, and Fieldbus control unit models to offer optimized solutions for customer needs.Versatility and Flexibility: A wide range of scanner and control unit combinations allows for application in diverse scenarios, easy individual system retrofitting, and the provision of Basic, Premium, and Fieldbus control unit models to offer optimized solutions for customer needs.
- Easy Installation and Maintenance: The mechanical contact-based system ensures simple installation, requires virtually no maintenance, and operates without complex adjustments, thereby enhancing operational efficiency.Easy Installation and Maintenance: The mechanical contact-based system ensures simple installation, requires virtually no maintenance, and operates without complex adjustments, thereby enhancing operational efficiency.
- Increased Productivity and Quality: Immediate machine stop signals upon fault detection minimize production downtime, reduce waste generation, and significantly improve overall production quality and productivity.Increased Productivity and Quality: Immediate machine stop signals upon fault detection minimize production downtime, reduce waste generation, and significantly improve overall production quality and productivity.
- German Engineering Excellence: The 'Made in Germany' designation signifies superior engineering capabilities and a high reputation in the international market, serving as a strong guarantee for product quality and reliability.German Engineering Excellence: The 'Made in Germany' designation signifies superior engineering capabilities and a high reputation in the international market, serving as a strong guarantee for product quality and reliability.
- Target Industries
- Machine building industryMachine building industry
- Metal working industryMetal working industry
- Automotive production industryAutomotive production industry
- Medical device production industryMedical device production industry
- CNC machines and automated production processesCNC machines and automated production processes
- Automated production plants such as machining centers, rotary transfer machines, transfer lines, machine tools, and special machinesAutomated production plants such as machining centers, rotary transfer machines, transfer lines, machine tools, and special machines
- Major Markets
- Japan, India, China, South Korea, Taiwan, Thailand, SingaporeJapan, India, China, South Korea, Taiwan, Thailand, Singapore
- Germany, Portugal, SwitzerlandGermany, Portugal, Switzerland
- USA, MexicoUSA, Mexico
- BrazilBrazil
- Certifications/Patents
- CE Mark: Compliance with EEC Directive 89/336/EEC on electromagnetic compatibility requirements.CE Mark: Compliance with EEC Directive 89/336/EEC on electromagnetic compatibility requirements.
- Compliance with UL 508 specifications.Compliance with UL 508 specifications.
- IP67 protection rating for scanners (some models are IP64).IP67 protection rating for scanners (some models are IP64).
- Development capabilities for intelligent sensor system solutions based on decades of technological knowledge and industry-specific application experience.Development capabilities for intelligent sensor system solutions based on decades of technological knowledge and industry-specific application experience.
