HOMO MIXER (Batch Type Mixer for Homogenizing)

HM-Series







HM1LH(0.25HP MIXING PART)

This is specially fabricated Homo Mixer main body for emulsifying and dispersing of small amount of material in vial with small inlet.
Size: Mixer body-W140xD180xH400(mm)



HM1QT(Standard Manual Stand)

This is specially fabricated Homo Mixer main body for emulsifying and dispersing of small amount of material in vial with small inlet.
This is standard product consists of stand(lift), mixing part and controller.
Size is shown in the drawing in specification page.



HM1LH(Example of Use)

It can use the small material which has small inlet and small quantity ,
so it is suitable for small emulsification and dispersion in pharmacy and bio industry.



ROTOR

This Rotor is fabricated for adopting small diameter Stator with special design for powerful dispersion.
Size-Φ25x 25 mm



STATOR

This small diameter Stator is useful in pharmacy and bio industry, designed specially for dispersion of small amount or input into small size vial inlet.
Size-Φ25x 40 mm


HM1QT(Standard Manual Stand)

This is a Homo Mixer specially made to emulsify and disperse a small amount of material inside a small neck bottle.
This standard product comprises of a Stand (Lift), a Mixing Unit and a Controller in one. Please refer to the drawing in the Specification page for dimensions.



HM1QT(0.25HP MIXING PART)

his is the Main Body of Homo Mixer specially made to emulsify and disperse a small amount of material inside a small neck bottle.
Size: Main Body of the Mixer : W140xD180xH520(mm)



Electric Geared Stand)

This is an electrical geared stand where the upward and downward movement of the Lift is adjusted by simple button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).



HM1QT(VACUMM TYPE)

A homo mixer that enables a simultaneous vacuum mixing, fitted with a vacuum type flange can also be made to the user’s individual requirements. (optional)



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ45x 16 mm



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
size-Φ45x 35 mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


HM1HF(0.5HP MIXING PART)

This is the Main Body of Homo Mixer exclusively used in laboratories, offering powerful dispersion and emulsification capacities.
When combined with an existing tank, it can be used for pre-mixing too.
Size: Main Body of the Mixer : W160xD180xH600(mm)



HM1HF(Standard Manual Stand)

This is a standard product comprising of a Main Body of Homo Mixer having powerful emulsification and dispersion capacities for laboratories, a Stand (Lift) and a Controller in one.
Please refer to the drawing in the Specification page for dimensions.



HM1HF(Electric Geared CASE TYPE)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ60x 17 mm



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
size-Φ60x 35mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height.



HM001(1HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



HM001(LIFT UP & DOWN)

Upon filling a tank, the Lift can be moved up or down by button operation, making it easy even for female and elderly operators.



ROTOR

This constitutes an impeller together with a Stator.It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ65x 34 mm



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
Compatible Impeller - Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)
size-Φ65x 41mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height.



HM003 (3HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



IMPELLER

This spins at high speeds while maintaining a fine gap (0.2mm) between the ROTOR and the STATOR, offering the optimum result through powerful absorption and dispersion capacities.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ79x 27 mm



STATOR

This is a stator for Homo Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
size-Φ140x 47mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height.
size:Φ85 x 35mm(optional)



HM005(5HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



HM005(MIXING PART)

This is the Main Body of Homo Mixer exclusively used in laboratories, offering powerful dispersion and emulsification capacities.
When combined with an existing tank, it can be used for pre-mixing too.
size: W310 x D310 x H1280(mm)



IMPELLER

This spins at high speeds while maintaining a fine gap (0.2mm) between the ROTOR and the STATOR, offering the optimum result through powerful absorption and dispersion capacities.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ89x 41mm



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
size-Φ150 x 50mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height.
size:Φ100 x 35mm



HM010(10HP MIXING PART)

This is the Main Body of Homo Mixer exclusively used in laboratories, offering powerful dispersion and emulsification capacities.
When combined with an existing tank, it can be used for pre-mixing too.
size: W365 x D375 x H1600mm)



HM010(10HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



IMPELLER

This spins at high speeds while maintaining a fine gap (0.2mm) between the ROTOR and the STATOR, offering the optimum result through powerful absorption and dispersion capacities.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size-Φ110x 49mm



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.
size-Φ170 x 53mm



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height
size: Separate please contact.(optional)



HM020(20HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



HM020(20HP MIXING PART)

This is the Main Body of Homo Mixer exclusively used in laboratories, offering powerful dispersion and emulsification capacities.
When combined with an existing tank, it can be used for pre-mixing too
size: Separate please contact.



IMPELLER

This spins at high speeds while maintaining a fine gap (0.2mm) between the ROTOR and the STATOR, offering the optimum result through powerful absorption and dispersion capacities.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.
size: Separate please contact.



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)


AID IMPELLER

This part is installed on top of the impeller to help the impeller absorb floating materials having low specific gravity.
The number of this parts can be selected depending on the liquid height.)



HM030(30HP Electric Geared Stand)

This is a standard stand equipped with an electric gear that adjusts the upward and downward movement of the Lift by button operation.
It is virtually free of noise and vibration for enhanced user convenience (optional).
Please refer to the drawing in the Specification page for dimensions.



HM030(30HP MIXING PART)

This is the Main Body of Homo Mixer exclusively used in laboratories, offering powerful dispersion and emulsification capacities.
When combined with an existing tank, it can be used for pre-mixing too.



IMPELLER

This spins at high speeds while maintaining a fine gap (0.2mm) between the ROTOR and the STATOR, offering the optimum result through powerful absorption and dispersion capacities.



ROTOR

This constitutes an impeller together with a Stator.
It spins at a high speed together with its rotating shaft and maintains a find gap with the Stator to disperse and emulsify materials.



STATOR

This is a stator for Hono Mixer facilitating high shear by maintaining a fine gap with the Rotor and the special grooves.



Compatible Impeller

Homo mixers of K&S are compatible with various impellers (such as middle and low viscosity impellers, non-crushing impellers etc) making them truly versatile in many applications. (optional)
